UAV Searchlight
Zenmuse S1 is DJI's first spotlight designed for multi-payload drone platforms, compatible with DJI Matrice 400, Matrice 350 RTK and Matrice 300 RTK. Utilizing the LEP technology, it offers high brightness and long illumination distance, and supports multiple lighting modes. This makes it ideal for public safety, emergency rescue, inspection, and other nighttime operations.
Contact Us for Pricing
Interested in this product? Contact us now for detailed pricing and product information.
Product Details
Zenmuse S1 – Technical Parameters
| Product Name | Zenmuse S1 |
| Weight | 760±10 g |
| Dimensions | Length: 125 mm, Width: 152 mm, Height: 171 mm |
| Rated Power | 120 W (Matrice 400); 68 W (Matrice 300 RTK / Matrice 350 RTK) |
| Supported Models | Matrice 400; Matrice 350 RTK; Matrice 300 RTK (requires DJI RC Plus) |
| Eye Safety Rating | IEC 62471：Risk Group 1 |
| Shell Temperature | <50℃ (Plastic Shell) *Measured in laboratory environment with Zenmuse S1 mounted on aircraft at 25℃ ambient temperature* |
| Protection Rating | IP54 *Achieves IP54 protection rating under IEC 60529 standard in controlled laboratory conditions. Protection rating is not permanent and may decrease due to product wear* |
